FALCO Liquid Separator

The FALCO Liquid Separator (water knockout) removes liquids and mist from air streams in soil vapor extraction applications. The Separator is installed on the vacuum side of the blower to prevent liquid carryover to the blower and treatment system.

The drum has a removable lid. Inside a cage provides columnar support to the drum. A stainless ball float shuts off inlet flow when the drum is full.

Cutsheet

CAPACITY:
High level switch port: 35 gallons
Ball float shutoff: 43 Gallons
INLET: 3” OD Tubing
OUTLET: 3” NPT
CONSTRUCTION: 16 gauge steel-powder coated blue
WEIGHT: 77 pounds
MAXIMUM RATED VACUUM: 23 inches of Hg (312 inches H20)
PRESSURE DROP: 4 inches H20 @ 300 SCFM
